Aeromium Barcode Fonts
ITF14 Barcode
This is a barcode optimized for numbers, especially numbers with even number of digits. The numbers are encoded in a high density manner into the barcode. If the number of digits to be encoded is an odd number, a zero will be prepended.
Generating this barcode using the Barcode Maker
ITF14 is based on the Interleaved 2 of 5 barcode with an additional top/bottom bar called the bearers bar. During a scan, a barcode might be slanted and result in an incomplete read. The Bearers bar is used to prevent an incomplete read. This barcode is typically used to mark containers of products.
Generating this barcode using the Barcode Maker
Generating this barcode in Excel
ITF14 Barcode Fonts
The following is the list of fonts with varying heights supported by Aeromium.
FontITF14H1.ttf
FontITF14H2.ttf
FontITF14H3.ttf (Default Font)
FontITF14H4.ttf
FontITF14H5.ttf
FontITF14H6.ttf
Using this Barcode Manually
The following table lists the characters supported by the ITF14 barcode. Each barcode font character represents a 2-digit number.
| Data to be Encoded | Font Character to use |
| 00 | ' ' |
| 01 | '!' |
| 02 | '"' |
| 03 | '#' |
| 04 | '$' |
| 05 | '%' |
| 06 | '&' |
| 07 | ''' |
| 08 | '(' |
| 09 | ')' |
| 10 | '*' |
| 11 | '+' |
| 12 | ',' |
| 13 | '-' |
| 14 | '.' |
| 15 | '/' |
| 16 | '0' |
| 17 | '1' |
| 18 | '2' |
| 19 | '3' |
| 20 | '4' |
| 21 | '5' |
| 22 | '6' |
| 23 | '7' |
| 24 | '8' |
| 25 | '9' |
| 26 | ':' |
| 27 | ';' |
| 28 | '<' |
| 29 | '=' |
| 30 | '>' |
| 31 | '?' |
| 32 | '@' |
| 33 | 'A' |
| 34 | 'B' |
| 35 | 'C' |
| 36 | 'D' |
| 37 | 'E' |
| 38 | 'F' |
| 39 | 'G' |
| 40 | 'H' |
| 41 | 'I' |
| 42 | 'J' |
| 43 | 'K' |
| 44 | 'L' |
| 45 | 'M' |
| 46 | 'N' |
| 47 | 'O' |
| 48 | 'P' |
| 49 | 'Q' |
| 50 | 'R' |
| 51 | 'S' |
| 52 | 'T' |
| 53 | 'U' |
| 54 | 'V' |
| 55 | 'W' |
| 56 | 'X' |
| 57 | 'Y' |
| 58 | 'Z' |
| 59 | '[' |
| 60 | '\' |
| 61 | ']' |
| 62 | '^' |
| 63 | '_' |
| 64 | '`' |
| 65 | 'a' |
| 66 | 'b' |
| 67 | 'c' |
| 68 | 'd' |
| 69 | 'e' |
| 70 | 'f' |
| 71 | 'g' |
| 72 | 'h' |
| 73 | 'i' |
| 74 | 'j' |
| 75 | 'k' |
| 76 | 'l' |
| 77 | 'm' |
| 78 | 'n' |
| 79 | 'o' |
| 80 | 'p' |
| 81 | 'q' |
| 82 | 'r' |
| 83 | 's' |
| 84 | 't' |
| 85 | 'u' |
| 86 | 'v' |
| 87 | 'w' |
| 88 | 'x' |
| 89 | 'y' |
| 90 | 'z' |
| 91 | ASCII 176 |
| 92 | ASCII 177 |
| 93 | ASCII 178 |
| 94 | ASCII 179 |
| 95 | ASCII 180 |
| 96 | ASCII 181 |
| 97 | ASCII 182 |
| 98 | ASCII 183 |
| 99 | ASCII 184 |
| Start Character (Top/Down Bearers Bar) | '{' |
| Stop Character (Top/Down Bearers Bar) | '}' |
| Start Character (Rectangle Bearers Bar) | ASCII 190 |
| Stop Character (Rectangle Bearers Bar) | ASCII 191 |
Example
To encode the data "59348345668817" without the check digit manually, simply key in "{[BsMbx*}" and select the FontCodeITF14H3.ttf font. The output is as follows :
The "*" represents the number "10" where "1" is the last digit of the data and "0" is the check digit. The calculation of the check digit is illustrated in the section below.
How to calculate the check digit
For example if the data "59348345668810" is to be encoded as a barcode. The check digit is calculated as follows.
| Data | 5 | 9 | 3 | 4 | 8 | 3 | 4 | 5 | 6 | 6 | 8 | 8 | 1 | ||
| Starting from the last digit, multiply by 3 followed by 1. | |||||||||||||||
| *3 | *1 | *3 | *3 | *1 | *3 | *1 | *3 | *3 | *1 | *3 | *1 | *3 | |||
| Sum : | (5*1) + (9*3) + (3*1) + (4*3) + (8*1) + (3*3) + (4*1) + (5*3) + (6*1) + (6*3) + (8*1) + (8*3) + (1*1) = 140 | ||||||||||||||
| If Sum Mod 10 is 0, the result is 0. Otherwise the result is 10 - (Sum Mod 10) | |||||||||||||||
| Modulo 10 : | (140 % 10) = 0 | ||||||||||||||
| Data to be encoded | 59348345668810 | ||||||||||||||
| Mapping | 59 = '[' , 34 = 'B' , 83 = 's' , 45='M' , 66='b' , 88 = 'x' , 10 = '*' | ||||||||||||||
The characters "{[BsMbx*}" can then be keyed in to the text editor with the appropriate font selected to generate a ITF14 barcode with check digit.
